5x7 LED Dot Matrix Display Module
5x7 LED Dot Matrix Display Module
Product Overview
The 5x7 LED dot matrix display module is a compact industrial-grade LED character display designed for elevator systems, industrial equipment, and embedded control applications. It features low power consumption, high brightness, and stable long-term operation for professional OEM integration.
Square 5x7 LED matrix elevator display module
Key Features
- Low power consumption for energy-efficient operation
- High brightness for clear visibility in industrial environments
- Stable performance for long-term embedded system use
- Compatible with common cathode and common anode designs
Product Details
Houkem-1657-AW---------common cathode, row cathode (CC)
Houkem-1657-BW---------common anode, row anode (CA)
| Item No. | HOUKEM-1657-AW |
| Dimension | 20.4 × 35 × 6.5mm |
| Square Dot Size | 3 × 4mm |
| Surface Color | Black / Grey |
| Segment Color | White / Clear |
| Emitting Color | White |
Electrical & Optical Characteristics
Color Code & Chip Characteristic PEHIP (Test Condition: IF=15mA)
| Emitting Color | Wavelength (nm) | Forward Voltage (V) | Luminous Intensity (mcd) |
|---|---|---|---|
| Amber / Orange | 600–605 | 1.9–2.0 | 100–120 |
| Super Green | 565–575 | 1.9–2.0 | 48–55 |
| Super Red | 625–640 | 1.8–2.0 | 110–150 |
| Ultra Red 1 | 620–625 | 1.8–2.0 | 200–210 |
| Ultra Red 2 | 620–625 | 2.0–2.1 | 300–350 |
| Blue | 465–475 | 2.95–3.0 | 150–200 |
| Pure Green | 515–525 | 2.95–3.0 | 600–640 |
| White | - | 2.8–3.0 | 200–220 |
Applications
- Elevator floor indicator display systems
- Industrial equipment status indicators
- Embedded controller display modules
- Instrumentation and panel display solutions
Product Range & Compatibility
We also manufacture a wide range of LED display solutions:
- 5x7, 5x8, 8x8, 11x7, 16x16 LED dot matrix modules
- 7 segment LED displays (multi-digit options)
- 14/16 segment alphanumeric displays
- Custom LED display solutions available
Our Services
Custom 7 segment display and LED matrix solutions are available for OEM/ODM industrial projects.
Our valid EU‑related certifications include CE, RoHS 2.0, REACH (SVHC), EMC. We are able to provide complete MSDS (Material Safety Data Sheet) documents for customers upon request.
All our LED products follow EU EMC directive, RoHS hazardous‑substance restrictions and REACH chemical regulations. Full certification files can be supplied before shipment.
