Model No: Houkem-3132
Full color customized 7 segment display oem/odm seven segment display
customized 7 segment led display houkem is customized 7 segment display professional manufacturer
Delivery :
EXW
minimum order :
1000 pieces
Supply Ability :
100000pieces / Month
Stock Time :
7-14Day
Country of Origin :
Dongguan/ Guangdong
Quantity :
US $3.00 - US $10.00 / pieces
- Place of Origin:CN;GUA
- Usage:Indoor
- Tube Chip Color:FULL COLOR
- Display Function:Graphics
- Pixels:20mm
- Brand Name:KEM
- Model Number:Houkem-3132
- Screen Dimension:63.9*36.9mm
Product Describtion
Customized display led 7 segment display oem/odm seven segment display
| Item No. | Houkem-3132 |
| Surface color | Black /Grey |
| epoxy color | white |
| Emitting color | full color |
Two years quality warranty
1,Low power consumption
2, High brightness
3, High intensity and reliability
4, Easy assembly
Color Code & Chip characteristic PER CHIP: (Test Condition: IF=20Ma)
Emitting Color | Test Condition | Wavelength(nm) | Forward Voltage(V) | Luminous Intensity (mcd) | |||
(λp) | λ | Typ | Max | Typ | Max | ||
Amber | IF=18mA | 600-605 | 30 | 1.9 | 2.0 | 90 | 100 |
Super green | IF=18mA | 565-575 | 30 | 1.9 | 2.0 | 48 | 55 |
Super red | IF=18mA | 620-625 | 20 | 1.8 | 2.0 | 110 | 130 |
Ultra red | IF=18mA | 620-625 | 20 | 2 | 2.1 | 300 | 350 |
High red | IF=18mA | 638-660 | 20 | 1.8 | 1.9 | 15 | 20 |
Yellow green | IF=18mA | 570-580 | 30 | 1.9 | 2.0 | 43 | 50 |
Yellow | IF=18mA | 580-600 | 35 | 1.9 | 2.0 | 70 | 80 |
Blue | IF=20mA | 465-475 | 40 | 2.8 | 3.0 | 150 | 200 |
Pure green | IF=20mA | 515-525 | 40 | 2.8 | 3.0 | 180 | 250 |
White | IF=20mA | - | - | 2.8 | 3.0 | 180 | 200 |
Our Services
oem service:
Please send your drawing to us, we will design the products as you need.
Custom service:
1. We can supply you all kinds of 7 segment LED display
---Digit size: from 0.25"to 20"
---Digit Numer: 1, 2, 3, 4, 5 and 6 digits
2. Segment : 7 segment and 14 segment both available
3. Various colors: super red, ultra red, high red, yellow green, pure green, super green,
pure green, blue, yellow, white, amber, Bi-color, RGB.
Working Process
Application
Packaging & Shipping
Contact us
Lydia Su
Skype ID: wood3701
Phone: +86 13129213536
Wechat: 13129213536
QQ:1039243252
Established in 2003,our factory is specialized in LED products, including 7 segment
LED/SMD displays,Alphanumeric displays,SMD LEDs,dot-matrix Led displays,bar graph
arrays and LED directon indicator displays.etc.
