Model No: Houkem-21616-RGB

16x16 RGB LED Matrix Panel Module

HOUKEM 16x16 RGB LED Matrix Panel Module features a compact 40×40mm design, SMD RGB LEDs and 5V operation for embedded displays, visual indicators and custom electronic equipment. OEM buyers can request technical specifications and configuration details for project evaluation.
Quantity :
add to cart
Contact Now

16x16 RGB LED Matrix Panel Module

The HOUKEM 16x16 RGB LED Matrix Panel Module is a compact display component featuring a 16×16 LED array and a 40×40mm panel design. It is intended for embedded electronic equipment, compact visual displays and OEM display integration.

The module uses RGB SMD LEDs and has a published 5V DC operating voltage. Buyers should confirm the control IC, electrical interface, pixel pitch and power requirements before integrating the module into a controller-based system.

HOUKEM supports OEM and ODM inquiries for LED matrix products. Equipment manufacturers can provide their required dimensions, display configuration, electrical specifications and order quantities for technical evaluation.

Key Features

  • 16×16 RGB LED matrix configuration

  • Compact 40×40mm panel dimensions

  • SMD RGB LED design

  • Published 5V DC operating voltage

  • Suitable for compact display and indicator applications

  • OEM/ODM configuration inquiries supported

  • Technical specifications available for project evaluation

Product Specifications

Parameter

Specification

Product Name

16x16 RGB LED Matrix Panel Module

Model Number

Houkem-21616-RGB(待确认)

Display Array

16 × 16

Nominal Pixel Positions

256

Panel Dimensions

40 × 40mm

Emitting Color

RGB

LED Type

SMD RGB LED

Operating Voltage

5V DC

Pixel Pitch

To be confirmed

Control IC

To be confirmed

Control Interface

To be confirmed

Applications

Embedded displays, visual indicators, OEM equipment

Product Images

Electrical Parameters

Parameter

Published Value

Notes

Module Operating Voltage

5V DC

Module-level supply specification

LED Forward Voltage

1.8–3.0V

Varies by LED color; confirm test conditions

LED Forward Current

18–20mA

Confirm whether per chip or per color channel

Luminous Intensity

15–300mcd

Confirm applicable color and test current

The electrical values above are based on the published product information. Module-level power requirements and individual LED characteristics should be evaluated separately.

For circuit design, confirm the control IC, interface configuration, current requirements and applicable electrical limits using the latest technical documentation.

Control IC and Interface Requirements

The control IC and electrical interface are important considerations when integrating a 16x16 RGB LED matrix into an embedded display system.

Different LED matrix designs may use different driving methods, signal connections and control architectures. Therefore, buyers should not assume that all 16x16 RGB LED panels support the same controller or software library.

Confirm the Control IC and Signal Interface

Before selecting the module, request the control IC identification and the corresponding interface information.

The technical documentation should clarify the required control signals, connection arrangement and any external driver requirements.

Check Arduino and ESP32 Compatibility

Arduino or ESP32 integration depends on the actual control architecture of the LED matrix.

Developers should verify the required operating voltage, signal levels, communication method and compatible software before beginning circuit development.

Review Power and Connection Requirements

The published operating voltage is 5V DC. However, the complete module's current consumption and power requirements must be confirmed for the intended operating conditions.

For OEM integration, request the relevant connection diagram, electrical specifications and available control documentation before finalizing the equipment design.

Applications of the 16x16 RGB LED Matrix Panel

The compact RGB LED matrix format can be considered for several embedded display applications, depending on the required control interface, viewing conditions and electrical configuration.

  • Embedded electronic equipment and visual indicators

  • Compact RGB information displays

  • Custom electronic control panels

  • Small-format display and demonstration systems

  • OEM electronic products requiring RGB matrix visualization

For Arduino, ESP32 or other controller-based applications, confirm the control IC and interface requirements before integration.

QUALITY ASSURANCE
Certificates & Quality Standards
As a professional LED manufacturer, our 7 segment led display,7 segment smd display,dot matrix,ir led,uv led,high power led fully comply with European Union import requirements.
Our valid EU‑related certifications include CE, RoHS 2.0, REACH (SVHC), EMC. We are able to provide complete MSDS (Material Safety Data Sheet) documents for customers upon request.
All our LED products follow EU EMC directive, RoHS hazardous‑substance restrictions and REACH chemical regulations. Full certification files can be supplied before shipment.
Certificate 01
UR / IR LED RoHS Certificate
01
Certificate 02
UR / IR LED SVHC Compliance Certificate
02
Certificate 03
7-Segment LED Display Certificate
03
Certificate 04
7-Segment LED Display Certificate
04
Certificate 05
UR / IR LED CE Certificate
05
Certificate 06
7-Segment LED Display Certificate
06
Certificate 07
UR / IR LED EMC Certificate
07
Certificate 08
7-Segment LED Display Certificate
08




Company Profile

Houkem is a professional LED manufacturer with over 18 years of experience in LED display modules, dot matrix LEDs, and SMD LED solutions. We provide OEM/ODM services for global industrial and commercial clients.

Frequently Asked Questions (FAQ)

Is this 16x16 RGB LED matrix compatible with Arduino or ESP32?

Compatibility depends on the module's control IC and interface configuration. Before integration, request the relevant electrical and control documentation from HOUKEM to verify compatibility with your selected controller.

Does this RGB LED matrix include a built-in control IC?

The product is described as an RGB LED matrix with an integrated IC design. Buyers should confirm the exact IC model, signal interface and control method with HOUKEM before selecting the module for an embedded system.

What is the operating voltage of the 16x16 RGB LED matrix panel?

The published module operating voltage is 5V DC. The complete power requirements depend on the module configuration and operating conditions. Request the latest electrical specifications before designing the power supply.

Can it be used for advertising displays?

Yes, it is widely used in compact digital signage systems.

Do you support OEM customization?

Yes, we support OEM/ODM customization for size, color, and structure.

Request a 16x16 RGB LED Matrix Quote

Looking for a compact 16x16 RGB LED matrix panel for embedded equipment or an OEM display project?

Contact HOUKEM with your required panel dimensions, control interface, electrical specifications, estimated quantity and application details to discuss model availability, technical documentation and bulk pricing.
