8x8 RGB LED Matrix Display Module
RGB LED Matrix Display Overview
TheRGB LED Matrix Display is a compact and reliable 8×8 LED module designed for industrial electronics, digital displays, control systems, and OEM applications. Manufactured by Houkem, this RGB Dot Matrix Display integrates red, green, and blue LED technology to provide flexible color output, uniform brightness, and stable performance for professional electronic equipment.
Featuring an 8×8 RGB LED Matrix structure with a compact 37.9 × 37.9mm panel size, this module is ideal for applications requiring colorful indicators, message displays, digital interfaces, and embedded visual solutions.
With low power consumption, a long service life of up to 50,000 hours, and customizable configurations, Houkem’s RGB LED Matrix Display provides reliable solutions for industrial equipment manufacturers, electronic product developers, and OEM customers worldwide.
Product Features
Key Advantages
- 8×8 RGB LED matrix structure
- RGB emitting colors: Red, Green, and Blue
- Compact module size: 37.9 × 37.9mm
- Pixel pitch: 2.54mm
- Pixel size: 3.7mm
- Uniform light emission and excellent color consistency
- Low current consumption
- Available in common anode and common cathode configurations
- Long service life up to 50,000 hours
- CE and RoHS compliant
- 2-year warranty
- OEM and customized solutions available
Technical Specifications
| Item | Specification |
|---|---|
| Product Name | RGB LED Matrix Display |
| Part Number | Houkem-15088-ARGB |
| Model Number | Houkem-15088-BRGB |
| Dot Array | 8 × 8 |
| Panel Size | 37.9 × 37.9mm |
| Pixel Size | 3.7mm |
| Pixel Pitch | 2.54mm |
| Surface Color | Black / Grey |
| Epoxy Color | Milky White / Clear |
| Emitting Color | Red + Green + Blue |
| Luminous Intensity | 80–100mcd/chip |
| Forward Voltage | 1.8–2.0V |
| Forward Current | 18mA |
| Polarity | Common Anode / Common Cathode |
| Life Span | 50,000 Hours |
| Certification | CE, RoHS |
| Warranty | 2 Years |
Available LED Color Options
RGB LED Matrix Display Color Selection
Houkem provides different LED wavelength options to meet various display requirements. Customers can select different colors and brightness levels according to their application needs.
| Color | Wavelength | Forward Voltage | Forward Current | Luminous Intensity |
|---|---|---|---|---|
| Super Red | 630–635nm | 1.8–2.0V | 18mA | 100–150mcd |
| High Red | 638–660nm | 1.8–1.9V | 18mA | 15–20mcd |
| Ultra Red | 620–625nm | 2.0–2.1V | 18mA | 200–300mcd |
| Super Green | 565–575nm | 1.9–2.0V | 18mA | 48–55mcd |
| Pure Green | 615–625nm | 2.8–3.0V | 20mA | 260–300mcd |
| White | — | 2.6–2.8V | 20mA | 200–250mcd |
| Blue | 465–475nm | 2.8–3.0V | 20mA | 150–200mcd |
| Yellow | 580–600nm | 1.9–2.0V | 18mA | 70–80mcd |
| Amber | 600–605nm | 1.9–2.0V | 18mA | 100–110mcd |
For special wavelength requirements, customized brightness levels, or other LED colors, Houkem’s engineering team can provide professional solutions.
Applications of RGB LED Matrix Display
Industrial and Electronic Applications
TheRGB LED Matrix Display is widely used in professional electronic products where compact size, multiple colors, and stable operation are required.
Typical applications include:
- Industrial equipment LED displays
- Digital clock displays
- Home appliance control panels
- Advertising and message boards
- Smart electronic devices
- Embedded control systems
- Instrument panels
- Information display equipment
- Custom OEM electronic products
The 8×8 RGB LED matrix structure allows engineers to create colorful visual indicators and information displays while maintaining reliable electrical performance.
OEM Custom RGB LED Matrix Solutions
Customized Manufacturing Capability
As an experienced LED display manufacturer, Houkem provides OEM and ODM services for customers requiring customized RGB LED Matrix Displaysolutions.
Available customization options include:
- RGB LED configuration
- Common anode or common cathode design
- Pin arrangement
- Module dimensions
- Brightness requirements
- LED wavelength selection
- Packaging solutions
- Customer logo customization
With more than 18 years of LED manufacturing experience and an ISO 9001 certified quality management system, Houkem supports customers from prototype testing to mass production.
All products are tested before shipment to ensure stable electrical performance, consistent brightness, and reliable long-term operation.
Why Choose Houkem?
Professional LED Display Manufacturer
Houkem specializes in LED display manufacturing and provides reliable solutions for global electronic manufacturers.
Advantages include:
- 18+ years LED manufacturing experience
- Original factory manufacturer
- Factory-direct pricing
- Professional R&D team
- CE and RoHS certified products
- Strict quality inspection process
- Sample orders available
- Fast production support
- Global logistics service
Our goal is to provide high-quality RGB LED Matrix Display modules for industrial, commercial, and OEM electronic applications.
Frequently Asked Questions
Can Houkem customize RGB LED Matrix Display modules?
Yes, Houkem provides OEM and ODM customization including size, brightness, LED color, pin configuration, and packaging solutions.
What applications use an 8x8 RGB LED Matrix?
The 8×8 RGB LED Matrix is commonly used in industrial displays, smart devices, control panels, advertising equipment, and embedded electronic products.
Does this RGB LED Matrix Display support different polarity options?
Yes, both common anode and common cathode versions are available for different circuit design requirements.
Can customers request samples before bulk production?
Yes, Houkem accepts sample orders for testing and quality verification before mass production.
What is the production lead time for OEM orders?
Sample orders usually require 3–7 days when products are available, while mass production normally takes 20–30 days depending on quantity and customization.
Request a Quote for RGB LED Matrix Display
Looking for a reliable RGB LED Matrix Display manufacturer for your electronic project?
Contact Houkem today for technical consultation, sample testing, OEM customization, and factory quotation. Our professional LED engineers are ready to provide the right RGB matrix solution for your application.
Our valid EU‑related certifications include CE, RoHS 2.0, REACH (SVHC), EMC. We are able to provide complete MSDS (Material Safety Data Sheet) documents for customers upon request.
All our LED products follow EU EMC directive, RoHS hazardous‑substance restrictions and REACH chemical regulations. Full certification files can be supplied before shipment.
