5x7 Red LED Matrix Display 1.9mm
5x7 Red LED Matrix Display 1.9mm for Industrial Applications
HOUKEM 5x7 LED Matrix Display is a compact LED display module designed for industrial equipment, elevator displays, graphic message systems, and embedded display applications. With a 1.9mm dot matrix structure, high brightness red LED chips, and reliable performance, this mini LED dot matrix display provides clear character and graphic information output for professional electronic applications.
As an experienced LED display manufacturer, HOUKEM provides standard and customized LED display solutions with OEM and ODM support. Our 5x7 Red LED Matrix Display modules are manufactured with strict quality control and are suitable for customers requiring stable performance, long service life, and flexible customization.
Product Specifications
| Parameter | Description |
|---|---|
| Product Model | HOUKEM-7057-ASR |
| Product Name | 5x7 Red LED Matrix Display |
| Dot Matrix Format | 5x7 |
| Dot Size | 1.9mm |
| Dimension | 12.7 × 17.8 × 6.3mm |
| Emitting Color | Super Red |
| Surface Color | Black / Grey |
| Epoxy Color | White / Red / Transparent |
| PCB Polarity | Common Cathode |
| Display Function | Video, Picture, Graphic, Text Message |
| Material | GaAsPN + Plastic |
| Operating Temperature | -35 ~ +50℃ |
| Warranty | 2 Years |
| Certificate | CE / ROHS / ISO9001 / REACH |
| OEM / Customization | Available |
Compact 5x7 LED Matrix Display with Reliable Performance
The HOUKEM-7057-ASR 5x7 LED Matrix Display adopts a compact structure with a dimension of 12.7×17.8×6.3mm, making it suitable for applications where installation space is limited. The 5x7 dot arrangement enables clear display of numbers, letters, symbols, and simple graphic information.
This red LED matrix display uses high-quality LED chips to achieve stable brightness and uniform illumination. The low power consumption design helps reduce system energy requirements while maintaining excellent visibility in indoor and semi-outdoor environments.
The module supports common cathode connection and can be integrated into different electronic control systems. For customers requiring different colors, sizes, pin configurations, or PCB layouts, HOUKEM provides customized LED display module solutions based on specific project requirements.
LED Chip Characteristics
The 5x7 LED Matrix Display is available with different LED color options according to application requirements.
| Emitting Color | Wavelength | Forward Voltage | Luminous Intensity |
|---|---|---|---|
| Amber | 600-605nm | 1.9-2.0V | 90-100mcd |
| Super Green | 565-575nm | 1.9-2.0V | 48-55mcd |
| Super Red | 620-625nm | 1.8-2.0V | 110-130mcd |
| Ultra Red | 620-625nm | 1.8-2.0V | 200-350mcd |
| High Red | 638-660nm | 1.8-1.9V | 15-20mcd |
| Blue | 465-475nm | 2.95-3.0V | 150-200mcd |
| Pure Green | 515-525nm | 2.9-3.0V | 600-640mcd |
| White | - | 2.8-2.9V | 200-220mcd |
Applications of 5x7 LED Matrix Display
The HOUKEM 5x7 LED Matrix Display is widely used for professional display solutions, including:
Elevator Display Systems
The compact LED module can be integrated into elevator panels for floor numbers, status indicators, and information messages.
Industrial Equipment Displays
The module is suitable for embedded industrial equipment requiring reliable character and graphic information display.
Electronic Control Systems
OEM manufacturers can use this LED display module in customized control panels, instrument displays, and communication devices.
Graphic Message Displays
The 5x7 LED Matrix Display supports basic text and symbol presentation for advertising, notification, and information systems.
Why Choose HOUKEM LED Display Modules
Established in 2003, HOUKEM specializes in the research, development, production, and sales of LED display products. Our product range includes 7 segment LED displays, SMD LED displays, alphanumeric displays, dot matrix LED displays, bar graph arrays, and customized LED solutions.
With advanced production equipment, strict quality control processes, and certifications including CE, ROHS, ISO9001, and REACH, HOUKEM provides reliable LED display components for global OEM customers.
We support sample orders, bulk production, customized designs, and professional technical service to help customers develop efficient display solutions.
FAQ
What applications are suitable for the 5x7 LED Matrix Display?
This module is designed for elevator displays, industrial equipment, embedded systems, and graphic message applications.
Can HOUKEM customize the LED Matrix Display?
Yes, HOUKEM provides OEM and ODM customization including color, size, PCB layout, polarity, and packaging options.
What is the minimum order quantity for samples?
Sample orders are available, and customers can order individual units for testing and quality evaluation.
What certifications does this LED display module have?
The product complies with CE, ROHS, ISO9001, and REACH standards to support international industrial applications.
How long is the warranty period?
HOUKEM provides a 2-year quality warranty with professional after-sales support for LED display products.
Contact HOUKEM for Your LED Display Project
Whether you need a standard 5x7 LED Matrix Display or a customized LED display module for your application, HOUKEM can provide factory-direct solutions with reliable quality and technical support.
Contact our team today for datasheets, samples, customization options, and bulk quotation.
