293nm 295nm 3535 SMD high power 1W UVB LED for Vitamin D
- Input Voltage(V):DC 5.5-6V
- Warranty(Year):2-Year
- Type:High Power LED
- Support Dimmer:NO
- Lighting solutions service:Lighting and circuitry design
- Luminous Efficacy(lm/w):26
- Lifespan (hours):10000
- Working Time (hours):10000
- Product Weight(kg):0.001
- Chip Material:AlGaInP
- Emitting Color:purple
- Luminous Intensity:30mw
- Power:1w
- Viewing Angle(°):60
- Operating Temperature(℃):-20 - 60
- Storage Temperature(℃):-40 - 80
- Place of Origin:Guangdong, China
- Brand Name:HOUKEM
- Product name:1W High Power uvb LED 295nm
- Emitting Colour:puple
- Forward Voltage:5.5-6v
- Warranty:2 Years
- Wave length:290-300nm
- Current:200mA
- Chip Size:30*30mil
- Application:Medical Treatment, phototherapy
- Certification:RoHS,CE,ISO9001
- Chip brand:pw
High power 1w 298nm 293nm 295nm uv b led
Electrical and optical characteristics (Ta = 25℃, If=200mA)
Parameter | Symbol | Test Condition | Value | Unit | ||
Min. | Typ. | Max. | ||||
Forward Voltage | VF | IF = 200mA | 5 | 5.8 | 6 | V |
Radiant Flux [mW] | mW | IF = 200mA | 22 | 25 | 30 | mw |
Viewing Angle | 2θ1/2 | IF = 200mA | ---- | 60 | ---- | Deg. |
Dominate Wavelength | λd | IF = 200mA | 290 | -- | 300 | nm |
Features and Benefits
• Deep ultraviolet LED
• Low thermal resistance
• SMT solderable
• Lead Free product
• RoHS compliant
• High Luminous intensity
• Long Operation Life
Key Applications
• Blood Analysis
• Phototherapy
• Spectroscopy for Medical &
Scientific application
• Deodorization
led light
